EX9133C-2 – Serial to Ethernet Converter (RS422/485*1, RS232*1)
CAD$165.00
With the help of EX9133C-2 RS422 / RS485 Ethernet Converter, you can easily integrate serial devices in a LAN-network.
Description
With the EX9133C-2 Serial to Ethernet Converter (RS422/485*1, RS232*1), you can easily integrate serial devices in a LAN-network. The EX9133C-2 has two connectors, one RS232, and one RS422/RS485. The Ethernet Converter can be operated in a wide temperature range. Set up is easy because all configuration parameters can be set with a web interface. Virtual Com Software for Windows system can be downloaded for free (see download tab).
Additional information
| Weight | 1 lbs |
|---|
Specifications
| Specifications | |
| System RAM: | 128 kb |
| Flash ROM: | 512 kB |
| Ethernet port: | 1 |
| Speed: | 10/100 Base T |
| Connector: | RJ45 |
| RS-232 Ports: | 1 |
| Speed: | 300~115200 bps |
| Connector: | DB9 female |
| RS-422/485 Ports: | 1 |
| Speed: | 300~115200 bps |
| Connector: | screw terminal block |
| Power consumption: | 3.5 W |
| Operating Temperature: | + 0 °C to + 70 °C |
| Storage Temperature: | – 10 °C to + 70 °C |
| Indicator: | LED |
| Included in delivery | |
| Driver CD: | 1 |
| Manual: | 1 |
Product Compare
|
Ethernet
|
RS232
|
RS422
|
RS485
|
Isolation
|
Modbus RS485
|
Modbus RTU zu Modbus TCP
|
|
| EX9133C-RS232 |
RS232
|
||||||
| EX9133C-RS485 |
RS422 / RS485
|
||||||
| EX9133C-2 |
RS232 / RS422 / RS485
|
||||||
| EX9133C-2-MTCP |
RS232 / RS422 / RS485
|
: I/O 1, : I/O 2
