EX9051D-M – Modbus RTU 16 digital isolated input

Description

ExpertDAQ Digital Input module communicate via RS485 and are available with Modbus RTU. Within one RS485-network up to 256 modules may be controlled. Without an RS485 Repeater, the maximum cable length is 1200m. The RS485 Digital IO modules are sturdy, power saving and easy to use.

The EX9051D-M has 16 isolated channels with a high input impedance. The Digital Input RS485 module has a special input, allowing high input voltages for Digital Level 1. The Digital Input RS485 module has a LED-display for each channel and was developed for use in a wide temperature range.

Features:

• 16 digital inputs
• All inputs isolated
• Extended temperature range
• High input impedance
• Digital Level 0: <+1V – Digital Level 1: 10 – 50V
• Output as RS485-interface
• Communicate via Modbus-RTU
• Manual configuration or with supplied Software
• Power supply 10 – 30VDC
• Hard- and Software Watchdog
